CE Certification Door Light 774DLC-TU3
products description
Products description
· IP Architecture
Open and standard APl to work with third-party devices and systems.
· Easy to Install & Maintain
Door light is installed at/over the doors of patient rooms, which is easy to install and maintain.
· Robust Design
Solid contruction design.
· Documentation
Information will be documented in local HD and server.
Technical Data
| Model | TU3 |
| Dimension | 115*86mm |
| Lamp Color | Blue/Red/Yellow/Green (in default) |
| Material | ABS/Anti-UV/Fire-proof V-0 |
| Power Supply | DC 12V |
| Protocol Type | RJ45 10/100M, RS485 |
| Alarm | Sound & Light |
| Working Temperature | -10℃～+55℃ |
| Storage Temperature | -10℃～+60℃ |
| Humidity | 20%～85% |
Function
The door light is an alarm light that is installed at/over the doors of patient rooms to inform caregiver of each call type triggered by patient and caregiver.
• Call Display
4 LED lamps of different colors refer to different call types for caregiver for easy and rapid deployment. In addition, these different colors can light up simultaneously to notify caregiver.
• Self-inspection
Real-time self-inspection is conducted all the time. When it is unable to work or offline, alarm will be sent to nurse station before noticed by patient & caregiver.
• Management
Equipped with a controller, it can manage other devices in the patient rooms. When other devices cannot work or offline, sound and light alarm will be turned on.
Features
• Good mechanical properties with high resistance to daily stress (operation, cleaning, disinfection, jolts etc.)
• Suitable for use in care facilities with high standards of hygiene, stability, longevity and durability (continuous operation)
• 4 LED lamp colors for easy recognization of call types
• Delicate appearance fits in different decoration styles
• High visuality of LED lamp
• Impact resistant
• Protocol type: RS485 & TCP/IP
• RoHS-compliant
