Wholesale Bed Terminal 797M-HS26
products description
Products description
· IP Architecture
Open and standard APl to work with third-party devices and systems.
· User Friendly Interface
Bed terminal provides user-friendly operating interfaces to support the daily care processes in care facilities.
· Easy Install & Maintain
Bed terminal is placed at flexible brackets, which is easy to install and maintain.
· Robust Design
6H glass screen, metal fixed handset and solid contruction design.
· Documentation
Information will be documented in local HD and server.
Technical Data
| Material | Front & Medium: aluminum alloy; Back: ABS |
| Resolution | 1024*600 |
| Lifetime | MIN. 30000h |
| Working Temperature | -10℃～+55℃ |
| Power Supply | DC 12V/POE |
| Power Consumption | 10W |
| Standby Power Consumption | 2W |
| Dimension | 201*115*36mm |
| Touch Technology | Capacitive |
| Panel Size | 7-inch |
Function
Bed terminal, installed at the patient bed, is equipped with 7-inch LCD touch screen and is used for patients and caregivers.
Patients can use this terminal to perform:
• Nurse call
Bed terminal is equipped call button & handset, which is easy for patient to trigger a nurse call.
• Voice Communication
Patients can make a high-quality voice communication with caregivers effectively.
• Inquire
Patient can inquire daily diagnosis, treatment plans, surgical arrangements, related precautions, test result, medical order, payment status, vital signs etc.
• Message
Patient can check the message from caregivers, such as reminder, public announcement, audio/video.
Caregivers can use this terminal to perform:
• Assistant Call
Caregivers can use bed terminal or handset to make an assisstant call after the care unit is triggered.
• Call Following
When the caregiver is caring, another call is triggered from another patient. Bed terminal can act as Nurse Station to receive this call and intercom.
• Inquiry
Caregiver can inquiry medical order, medical tasks, care history.
• Timer
Caregiver can set timer, when care task is finished, automatically trigger one reminder to Nurse station.
• Guidance
With the bed terminal, caregivers can regularly push video or graphic guidance materials to patients and their families to provide health education and conduct targeted learning, which can significantly reduce the workload of nurses and improve the effectiveness of education.
• Bluetooth
The bed terminal supports Bluetooth connection to the third party devices. For example, to record vital signs and other information.
Features
• 7’ high-end bed terminal, stylish design with cutting-edge technology
• Good mechanical properties with high resistance to daily stress (operation, cleaning, disinfection, jolts etc.)
• Suitable for use in care facilities with high standards of hygiene, stability, longevity and durability (continuous operation)
• Intercom handset comply with ergonomics
• Cleaning mode to disinfect and clean
• Support front camera to video calls if allowed by care facilities or laws.
• Easy operation with touch screen
• UV/Impact/Heat/Fire resistant
• Antibacterial material
• RS485 interface, I/O input
• RoHS-compliant
System infrastructure
• Processor: Quad-core 64-bit Cortex-A53, 1.6GHz
• Memory: 2GB RAM, 32GB ROM
• Operating system: Android 10.0
• Video codec: H.264
• Audio codec: G.711/G.729
• Protocol type: TCP/IP, SIP, RTSP
