OEM Blue Code BLUEC770EB-AL7 Supplier

6.Blue Code BLUEC770EB-AL7.jpg

Blue code, designed with a distinguished appearance, is installed in patient rooms. It is equipped with an indicating light which can be easily noticed even in dark environment and won’t disturb patient. It is used for nurse to make a medical call after care unit was triggered, which can call medical team if medical assitance is needed.
Medical team is informed by nurse station, doctor station and corridor displays simultaneously with sound & light alarms.

    Contact us
    product details

    products description

    AL7 (2)
    797M-HL3 (6)rxi
    1732604487494
    797M-HL3 (5)213
    797M-HL3 (7)hfw
    797M-HL3 (3)78f

    Products description

    · Easy Install & Maintain
    Suitable for standard 86/80 wall box.
    · Robust Design
    Solid construction design.
    · Documentation
    Operation record will be documented in server.

    Technical Data

    Model AL7
    Dimension 86*86*12mm
    LED Indicator Support
    Material ABS/Anti-UV/Fire-proof V-0
    Power Supply DC 12V
    IP Grade IP30
    Working Temperature -10℃～+55℃
    Storage Temperature -10℃～+60℃
    Humidity 20%～85%

    Function

    It is used for nurses to make a medical call after care unit was triggered, which can call medical team when medical assitance is needed. It is installed in patient rooms where is needed.
    · Blue Code
    Nurses can trigger the Blue Code to inform medical team when medical emergency happens.
    · Blue Code Cancellation
    Medical team can cancel the Blue Code by pressing the button or using IC card when arriving.
    · Cleaning Mode
    After long pressing the button for 10s, indicator starts blinking and cleaning mode turns on. Cleaning mode turns off automatically after 15s.
    · Self-inspection
    Real-time self-inspection is conducted all the time. When it is unable to work or offline, alarm will be sent to nurse station before noticed by patient & caregiver.
    · Documentation
    Details about trigger time, trigger location, cancel time, cancel location and cancel operator (if IC card is applied) will be recorded.

    Features

    • Standard 86 size, 86/80 wall box
    • Button pressing & IC card are both supported
    • Recognizable appearance: one button only, backlight, marked with ‘CODE’
    • STAFF ONLY marked to avoid mis-operation
    • Good mechanical properties with high resistance to daily stress (operation, cleaning, disinfection, jolts etc.)
    • Suitable for use in care facilities with high standards of hygiene, stability, longevity and durability (continuous operation)
    • Impact resistant
    • Protocol type: RS485
    • RoHS-compliant
